Close circuit hydraulic pump HP2VC 56/63/71/125/145/180
Axial piston variable pump in swashplate design for hydrostatic drives in closed circuits
Download:images/Hydraulic Pumps/Datasheet HP2VC Axial Piston Variable Pump.pdf
.png)
- Size：56/63/71/125/145/180 mL/r
- Rated pressure：400bar
- Max. pressure：450bar
- Axial variable pump in swashplate design forhydrostatic drives in closed circuits
- The flow is proportional to the drive speed anddisplacement and is infinitely varied
- The output flow increases from zero to the maximumvalue as the swashplate swivels
- The flow direction changes when the swashplate ismoved through the neutral position
- Various mutually compatible control options to providediverse control and regulation functions
- Two pressure relief valves on each high-pressureside to prevent overloading of hydrostatic drives(pump and motor)
- Pressure relief valve with boost function
- Integrated boost pump works as the boost andcontrol pump
- Maximum boost pressure limited by integratedboost-pressure relief valve
- With integrated pressure cut-off valve as standard
