Open Circuit Piston Pump A4VSO 40/71/80/125/180/200/250/355/ 370/500
Open Circuit Piston Pump A4VSO
.png)
- Robust high pressure pump for industrial applications
- Size 40ml/r-500ml/r
- Series 1, 2 and 3
- Nominal pressure 35MPa
- Peak pressure 42MPa
- Variable displacement axial piston pumpwith swashplate structure, designed for open circuit hydrostatic drives
- The flow is proportional to the drive speed and displacement, which can change steplessly by adjusting the swashplate angle
- Excellent suction characteristics
- Low noise level, long service life
- Drive shaft capable of absorbing axial and radial loads
- Modular design, good power/weight ratio
- Through drive for mounting additional pumps
- Swashplate angle indicator
- Optional mounting position
- Operation on HF fluids possible with reduced operating parameter
